| 원래 장소: | 중국 |
| 브랜드 이름: | HERONG |
| 인증: | CO, CE, ISO |
| 모델 번호: | K 시리즈 600‑2000VA |
| 최소 주문 수량: | 1 |
|---|---|
| 가격: | USD 1-1000 |
| 포장 세부 사항: | 표준 포장 또는 고객의 요청에 따라 |
| 배달 시간: | 지불금을 받은 후 영업일 기준 15-20일 |
| 지불 조건: | L/C,D/A,D/P,T/T,웨스턴 유니온 |
| 공급 능력: | 한달에 1000 |
CQ Series 1-10KVA High Frequency Online UPS with Dual Conversion and Wide Input Voltage Range
Office systems, surveillance systems, cash register systems in shopping malls and supermarkets, access control systems, emergency lighting equipment, emergency broadcasting systems, and network communication devices such as optical modems, routers, and switches.
| Model | 600VA | 1000VA | 1200VA | 1500VA | 2000VA |
|---|---|---|---|---|---|
| Capacity | 600VA / 360W | 1000VA / 600W | 1200VA / 720W | 1500VA / 900W | 2000VA / 1200W |
| Input | |||||
| Voltage | 220VAC | ||||
| Voltage range | 145-280 VAC | ||||
| Frequency | 50 Hz | ||||
| Output | |||||
| Voltage range (Battery mode) | 220VAC±10% | ||||
| Frequency range (Battery mode) | 50HZ±1HZ | ||||
| Change-over time | Generally 2-6 ms, with a maximum of 10 ms. | ||||
| Waveform (Battery) | Square wave | ||||
| Cell | |||||
| Battery type & quantity | 12 V7Ah x 1 | 12 V 9 Ah x 1 | 12 V 7 Ah x 2 | 12 V 9 Ah x 2 | 12 V 9 Ah x 2 |
| Charging interval | Charge to 90% in one hour | ||||
| Physical property | |||||
| Size, DXWTH (mm) | 335x87x143 | 312x122x195 | 360x122x195 | 360x122x195 | 360x122x195 |
| Net weight (kgs) | 4.4 | 6.9 | 8.4 | 11 | 12.3 |
| Unit set size, DXWTH (mm) | 392x142x205 | 403x225x295 | 443x223x295 | 443x223x295 | 443x223x295 |
| Pack rough weight (kgs) | 4.6 | 7.4 | 8.8 | 11.7 | 13 |
Overload, deep discharge, and overcharge protection
Relative humidity: 0-90%; Temperature: 0-40°C (non-condensing conditions)
담당자: Miss. Zeki
전화 번호: +8613601126185
